PRECISE TEMPERATURE CONTROL INTEGRATED INTO YOUR INJECTION MOLDING MACHINE
The powerful TempMaster M3 control platform can now be seamlessly integrated into any injection machine to eliminate the controller footprint. Featuring precise APS control technology and a wide range of advanced features, optimize the performance of any hot runner system. Unlock your operations full potential with TempMaster iM3.
Features
Seamless Integration
- OEM appearance.
- Eliminates the excess footprint of separate control equipment.
- Utilizes the existing HMI of the injection machine.
Incorporates TC-CONNECT Technology
- Replaces conventional T/C mold cables with a single lightweight data cable.
- Eliminating conventional T/C cables, which make up 50% of all mold cables, saves cost, weight, and clutter from the molding cell.
Advanced Features
- Provides enhanced hot runner functionality.
- Significantly improve molding process control and performance.
- Incorporates a variety of safety and protection features such as plastic leakage detection to protect the tool.
Easily Maintained
- Control cards are readily accessible.
- Can be swapped out any time within seconds.
Communication Ready
- Compatible with several industry standard protocols for superior flexibility and control.
- Built-in IO functions linked to machine interlocking.
Specifications
- Temperature Control Zones (Max): 48 @ 15A (Standard)
- Control Card Formats: 4-Zone (15A)
- Control Algorithm: APS (Adaptive Process System)
- Power Control: Phase Angle Burst Firing Modes (Time Proportional, Zero Crossing)
- Temperature Display Resolution: 1° (C or F)
- Power Response Time: 8.3ms at 60 Hz
- Temperature Scale: °C or °F (Software Selectable)
- Thermocouple: J or K-Type (Software Selectable)
- Output Voltage: 240V @415V Supply and 230V @400V Supply
- Supply Voltage: 200/240v 3P Delta or 380 to 415V 3P Star (other requires transformer)
- Communications: OPC-UA (Euromap 82.2), VNC, SPI, Powerlink, Modbus, EtherCAT.
- Languages: English, French, German, Portuguese, Spanish, Polish, Russian, Chinese, Japanese, Czech, Italian, Turkish.
*For more complete specifications, please refer to the product marketing literature in the “Downloads” section.
